| AUTOTECNICA GM0516484 Specifications |
|---|
| Amperage (A) | 14 A |
| Average Current Draw | 14 |
| Average Flow Rating | 52.8 GP |
| Bracket Included | No |
| Connector Color | White/Black |
| Connector Gender | Female |
| Connector Shape | Rectangular |
| Electric Or Mechanical | Electric |
| Fill Vapor Valve Included | Yes |
| Flow Rate (gph) | 52.8 GP |
| Flow Rate (lph) | 200 lp |
| Flow Restriction Pressure (psi) | 80 PS |
| Fuel Filter Included | No |
| Fuel Level Sensor Assembly Included | Yes |
| Fuel Level Vent Valve (FLVV) Included | Yes |
| Fuel Pressure Regulator Included | Yes |
| Fuel Sending Unit Included | Yes |
| Fuel Static Pressure (psi) | NA |
| Fuel Tank Pressure Sensor Included | Yes |
| Fuel Type | Gas |
| Gasket or Seal Included | Yes |
| Gasket Or Seal Material | NBR |
| Grade Type | Regular |
| Hardware Included | No |
| Height | 375 mm |
| Housing Length | 125 mm |
| Housing Material | POM |
| Housing Width | 125 mm |
| In Tank or External | In Tank |
| In-Line Pump | No |
| Inlet Attachment Method | Quick Connect |
| Inlet Diameter (IN) | .31 in |
| Inlet Diameter (MM) | 7.85 mm |
| Inlet Fitting Thread Size | NA |
| Inlet Fitting Type | Quick Connect |
| Inlet Outside Diameter | 7.85 mm |
| Inlet Quantity | 1 |
| Inlet Thread Diameter | NA |
| Inlet Type | Hose Port |
| Internal Or External Strainer | Internal |
| Intlet Fitting Thread Size | NA |
| Length | NA |
| Lock Ring Included | No |
| Manufacturer | Autotecnica |
| Maximum Flow Rating | NA |
| Maximum Free Flow Rate (gph) | NA |
| Maximum Pressure | 80 PS |
| Maximum Pressure (psi) | 80 PS |
| Minimum Flow Rating | NA |
| Minimum Free Flow Rate | NA |
| Minimum Free Flow Rate (gph) | NA |
| Minimum Pressure | NA |
| Module Included | Yes |
| Mounting Hardware Included | No |
| Negative Ground | Yes |
| Number of Connectors | 2 |
| Number of Mounting Holes | 0 |
| OE Part/Casting Number | 13513408 |
| Operating Pressure (psi) | NA |
| Outlet Attachment Method | Quick Connect |
| Outlet Diameter (IN) | .36 in |
| Outlet Diameter (MM) | 9.2 mm |
| Outlet Fitting Thread Size | NA |
| Outlet Fitting Type | Quick Connect |
| Outlet Outside Diameter | 9.2 mm |
| Outlet Quantity | 2 |
| Outlet Thread Diameter | NA |
| Outlet Type | Quick Connect |
| Pump Design | In Tank |
| Pump Type | Electric |
| Regulator Included | Yes |
| Resistance Ohms Empty | 248 |
| Resistance Ohms Full | 40 |
| Rheostat Range (Ohm) | 248-40 Oh |
| Rollover Valve Included | No |
| Shut Off Pressure (psi) | NA |
| Strainer Included | Yes |
| Strainer Location | Internal |
| Tank Seal Included | Yes |
| Terminal Gender | Male |
| Terminal Quantity | 7 |
| Terminal Type | Blade |
| Thermistor Low Fuel Indicator Included | No |
| Top Mount Diameter | 128.8 mm |
| Universal Or Specific Fit | Specific |
| Vapor Pressure Sensor Included | Yes |
| Vapor Vent Line Included | No |
| Voltage | 12 |
| Voltage (V) | 12 |
| Width | 125 mm |
| Wire Gauge Measurement | NA |
| Wire Harness Included | No |
| Wire Harness Length | NA |
| Wire Quantity | 0 |
