Оригинал. TRAKMOTIVE GM8506, Приводной вал CV, От 14140 Руб.
TRAKMOTIVE GM8506
TRAKMOTIVE GM8506
Приводной вал CV
| TRAKMOTIVE GM8506 Specifications | |
|---|---|
| Axle Nut Head Type | Hex |
| Axle Nut Height (MM) | 28 |
| Axle Nut Hex Size (MM) | 31.8 |
| Axle Nut Included | Yes |
| Axle Nut Length (MM) | 36.72 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M24*1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (IN) | 5/16 |
| Inboard Bolt Head Size (MM) | 8 |
| Inboard Bolt Head Type | Allen |
| Inboard Bolt Length (IN) | 2 3/4 |
| Inboard Bolt Length (MM) | 70 |
| Inboard Bolt Thread Size | M10*1.5 |
| Inboard Joint Type | Bolt-on |
| Inboard Shaft Connection Style | Bolt-on |
| New Or Remanufactured | New |
| Number Of Inboard Joint Bolt Holes | 6 |
| Number Of Inboard Shaft Bolts | 6 |
| Number of Outboard Splines | 30 |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Spline |
| Overall Compressed Length (IN) | 28.35 |
| Overall Compressed Length (MM) | 720 |
| Overall Extended Length (in) | 30.2 |
| Overall Extended Length (mm) | 767 |
| Производитель | TRAKMOTIVE |
| Оригинальный Номер | GM8506 |
| Описание | Приводной вал CV |
